DURAN® Vacuum Desiccator, NOVUS type
- With standard ground joint (24/29) junction tube in the lid, with stopcock, with flat flange
- Complies with DIN ISO 13130
- Manufactured from borosilicate glass 3.3
- Due to the high wall-thickness of the vessels and the exact machining of the vacuum-tight ground joints on the lid and base, storage under vacuum is possible – even over extremely long periods
- To accelerate the drying process, a vacuum can be applied via the stopcock
- Suitable for full vacuum (0 mbar)
- Spare parts such as lids, bases, stopcocks and caps can be interchanged as required (observe DN)
Product Specifications
| Catalog No | DN | ID Flange (mm) | Flange OD (mm) | Height h (mm) |
| GGD-24782.4604 | 100 | 119 | 153 ± 2 | 174 |
| GGD-24782.5703 | 150 | 172 | 215 ± 2 | 239 |
| GGD-24782.6108 | 200 | 224 | 270 ± 2 | 296 |
| GGD-24782.6605 | 250 | 274 | 320 ± 2 | 344 |
| GGD-24782.6905 | 300 | 332 | 380 ± 2 | 420 |
Available Options
| SKU | Description /size | Stocks | Unit Price (RM) | Quantity |
|---|---|---|---|---|
|
SKU: GGD-24782.4604 DURAN Vacuum Desiccator, NOVUS type, without plate, 100 mm (per pc) 3 units left |
DURAN Vacuum Desiccator, NOVUS type, without plate, 100 mm (per pc) | 3 units left | RM 1,393.37 |
RM 1,393.37
|
|
SKU: GGD-24782.5703 DURAN Vacuum Desiccator, NOVUS type, without plate, 150 mm (per pc) 5 units left |
DURAN Vacuum Desiccator, NOVUS type, without plate, 150 mm (per pc) | 5 units left | RM 1,648.77 |
RM 1,648.77
|
|
SKU: GGD-24782.6108 DURAN Vacuum Desiccator, NOVUS type, without plate, 200 mm (per pc) 5 units left |
DURAN Vacuum Desiccator, NOVUS type, without plate, 200 mm (per pc) | 5 units left | RM 1,872.65 |
RM 1,872.65
|
|
SKU: GGD-24782.6605 DURAN Vacuum Desiccator, NOVUS type, without plate, 250 mm (per pc) 5 units left |
DURAN Vacuum Desiccator, NOVUS type, without plate, 250 mm (per pc) | 5 units left | RM 2,096.76 |
RM 2,096.76
|
|
SKU: GGD-24782.6905 DURAN Vacuum Desiccator, NOVUS type, without plate, 300 mm (per pc) 5 units left |
DURAN Vacuum Desiccator, NOVUS type, without plate, 300 mm (per pc) | 5 units left | RM 2,634.24 |
RM 2,634.24
|
