MOTIC BA210 RED Binocular Microscope


Designed to be used in Educational Life Science, Medical as well as a variety of biological applications. The BA210 is a robust student instrument that brings professional, repeatable image quality results to all of its intended applications.



The new BA210 series is setting a new standard in microscope performance through inprovements both in optical and mechanical features. Designed to be used in Educational Life Science, Medical as well as a variety of biological applications, this new microscope is built around Motic's complete understanding of the daily demands placed on the standard educational microscope.

Student proof features together with a new generation of EF-N Plan Achromatic objectives provide a fully corrected intermediate image for crisp and clear visual and digital results.

The BA210 is a robust student instrument that brings professional, repeatable image quality results to all of its intended applications.

  • 30° inclined Binocular Siedentopf head for comfortable viewing while seated, rotates 360°
  • Interpupillary distance adjustment between 55-75mm
  • Widefield eyepieces N-WF10X/20mm with diopter adjustment on both eyepieces
  • Reversed quadruple nosepiece with click stops for precise magnification changes
  • CCIS EF-N Plan Achromatic objectives 4X/0.10, 10X/0.25, 40X/0.65 – Spring, 100X/1.25 – Spring/Oil
  • Coaxial coarse and fine focusing system with 2 micron minimum increment with tension adjustment
  • Vertical travel range 25mm
  • Large 140mm X 135mm mechanical stage with low-position coaxial controls. Travel range 76 X 50mm.
  • Focusable Abbe condenser N.A. 1.25 with iris diaphragm and slider slot.
  • LED illumination 3W with intensity control

Specifications

Model : BA210

Optical System : Color Corrected Infinity Optical System [CCIS®]

Obsevation Tube: Widefield binocular 30° [F.N. 20]

                             Widefield trinocular 30° [F.N. 20]- light distribution 100:0/20:80

Nosepiece : Reversed quadruple

Stage : 140 x 135mm surface; 76 x 50mm movement; coaxial controls

Condenser : N.A. 1.25 Abbe condenser with slider slot; Focusable and Lockable

Focus : Brass gears

             Z-Axis movement 25mm stroke

             Fine focus with 2µm minimum increment, Coarse focus with torque adjustment

Illumination : Built-in transmitted 6V/30W halogen critical illumination

                     Built-in transmitted 3W LED critical illumination; >10,000 hrs bulb life span Attachable Mirror set
