GENLAB Mino Economy Ovens

<div><strong>GENLAB Mino Classic Ovens</div>

GENLAB Mino Economy Ovens

• Direct reading thermostat and overheat indicator.
• Body powder coated, chamber aluminium coated mild steel.
• Shelves chrome wire type, temperature range from ambient to 250ºC.
• Conventional air circulation.

OVERVIEW

The GENLAB Mino Economy Ovens offer a range of highly efficient, reliable, cost effective units to suit most drying, warming and general laboratory app lications. The simple to use thermostat system is good for teaching purposes and the units can be built up to meet individual requirements.

Specifications

7 sizes 6 to 100 litres
Temperature range: 40ºC to 250ºC
Fluctuation +/- 0.75ºC
Easy clean powder coated body
Aluminium coated mild steel chamber
Direct reading thermostat
Safety overheat thermostat
Full two year warranty
C.E. compliant

Options

Stainless steel chamber (SS)
Fan circulation (F) (30 litre +)
Other options and accessories available on request

Mino Economy Oven Design

The exterior is constructed from sheet steel finished in an easy clean powder coated paint. The interior chamber is made from mild steel coated with aluminium (CLAD) with a stainless steel (SS) chamber available as an option.

Fitted with fixed shelf runners and removable chrome plated wire grid shelves.

Mino Economy Oven Heating

Heated by Incoloy sheathed elements, positioned below the chamber floor for natural convection units and fitted around the fan on the back wall of the chamber for mechanical convection units.

Mino Economy Oven Controls

The control system comprises of a direct reading thermostat and overheat thermostat, both with calibrated scales and tamper proof locks. They also include main switch with indicator and heat and overheat indicators.

FEATURES

Specifications

Genlab ref. Number	Capacity (litres)	Internal dims. (H x W x D cms)	External dims. (H x W x D cms)		No. of Shelves	No. shelf positions	Weight (kg)
Genlab ref. Number	Capacity (litres)	Internal dims. (H x W x D cms)	without fan	with fan	No. of Shelves	No. shelf positions	Weight (kg)
MINO/6	6	15 x 23 x 19	39 x 32 x 33	N/A	1	1	7
MINO/18	18	26 x 26 x 27	52 x 38 x 41	N/A	2	2	14
MINO/30	30	24 x 36 x 35	50 x 48 x 49	50 x 48 x 62	2	2	20
MINO/40	40	32 x 36 x 35	58 x 48 x 49	58 x 48 x 62	2	3	23
MINO/50	50	33 x 49 x 33	59 x 61 x 47	59 x 61 x 59	2	3	26
MINO/75	75	33 x 49 x 45	59 x 61 x 60	59 x 61 x 72	2	3	34
MINO/100	100	45 x 49 x 45	71 x 61 x 60	71 x 61 x 72	3	4	44

DOWNLOADS

Genlab MINO Oven

0.54 MB

Download
