LAUDA Hydro Vaporization Water Baths


- 5 model sizes (5 L to 19 liters volume)
- Heating capacity up to 1.5 kW
- Temperature range: +25 … 100 °C (boiling mode)
- Temperature stability: ±3 K
- Temperature adjustment via rotary knob with temperature scale
- Number of openings (1 to 8)
: All openings are provided with hole covers
: All hole covers consist of a multi-piece ring set and are removable
- Multi-piece ring set made of heat resistant plastic
- Adjustable water level regulator as standard

No product option available.

LAUDA Hydro vaporization baths operate in a temperature range from 25 to 100 °C. The opening diameter of the water bath can be variably changed in approx. 20 mm steps by means of the nine-part ring set. The models H 11 V, H 19 V were specially designed for protected working use in fume cupboards. The housings are made of stainless steel to allow evaporation work with chemically aggressive media.

Model Hydro H 5 V Hydro H 6 V Hydro H 9 V Hydro H 11 V Hydro H 19 V
Bath volume 5 L 5.3 L 9 L 10.5 L 18.4 L
Working temp. range 25 °C to 100 °C 25 °C to 100 °C 25 °C to 100 °C 25 °C to 100 °C 25 °C to 100 °C
Temp. stability 3 ±K 3 ±K 3 ±K 3 ±K 3 ±K
Heater power 1 kW 1 kW 1.5 kW 1.5 kW 1.5 kW
Bath opening 240 mm x 240 mm
Bath depth 120 mm 90 mm 90 mm 100 mm 100 mm
